Expansion Slots:

Option 1 - (2) PCI-E x16 LP; option 2 - (1) PCI-E x16 FP

Maximum Capacity:
up to 4096GB DIMM Memory Module, Adaptive Data Correction (SR),SDDDC, ADDDC

DIMM Slots Available:16 slots DIMM

DDR4: up to 2933 MHz DDR4 ECC Register

Memory protection:
Advanced ECC Registered Optane DC Persistent Memory Module (SDDC), Adaptive Data Correction (SR), SDDDC, ADDDC

Drive:
Front basket:
Optional 1 - (4) 3.5"/2.5" hot-plug SATA/SAS
Option 2 - (4) 3.5"/2.5" hot-plug SATA/SAS/NVMe
Option 3 - (10) 2.5" hot-plug SATA/SAS
Option 4 - (10) 2.5" hot-plug SATA/SAS/NVMe

Fans: Option 1 - (4+1) Hot-swappable, with redundancy; option 2 - (6+1) Hot-swappable, with redundancy

Interface:
Internal ports: (2) USB 3.0, (1) USB 3.0 Type A, (1) USB 2.0
External ports: D-Sub VGA based on Aspeed A ST 2600(1) COM external Dedicated 1 Gbit/s RJ-45 control port
Expansion ports: (2) SATADOM; (2) Hot-swap SD card; (2) M.2 2280 SATA/PCI-E; (4) OcuLink NVMe; USB 3.0

Disk Bays: (2) SATADOM

NIC: Option 1 - I350-1G, 2 ports, PXE-Boot support

Option 2 - I350-1G, 4 ports, PXE-Boot support

Storage Сontroller:
Intel RSTe 5.0 0/1/10/5; support VROC RAID 0/1/10/5 NVMe

Management:
Dedicated 1G control port based on Aspeed AST2600 controller
*Monitoring of the main temperature sensors (additional as part of the UtiNet View 2.x pack)
*Automatic fan speed control
*Support for KVM and Virtual Media functions
*Support for IPMI 2.0 and Redfish standards
*Protection built into the BIOS of the NSD (ViPNet SafeBoot)
*Case opening sensor
*RAID controller management (monitoring, VD creation/editing, NVMe management, controller fine-tuning)
