Expansion Slots:

Option 1 - (4) PCI-E x16 FP / (2) PCI-E x8 LP / (2) PCI-E x8 FP и (1) PCI-E x16 OCP Mezzanine; option 2 - (2) PCI-E x16 FP / (2) PCI-E x8 LP / (2) PCI-E x8 FP и (1) PCI-E x16 OCP Mezzanine

Maximum Capacity:
up to 7500GB DIMM Memory Module, Adaptive Data Correction (SR), SDDDC, ADDDC

DIMM Slots Available: 24 DIMM slots

DDR4: up to 2933 MHz DDR4 ECC Register

Memory protection:
Advanced ECC Registered Optane DC Persistent Memory Module (SDDC), Adaptive Data Correction (SR), SDDDC, ADDDC

Drive:
Front basket:
Optional 1 - (8) 3.5"/2.5" hot-plug SATA/SAS
Option 2 - (12) 3.5"/2.5" hot-plug SATA/SAS (4) 3.5"/2.5" hot-plug NVMe
Option 3 - (12) 3.5"/2.5" hot-plug SATA/SAS
Option 4 - (16) 2.5" hot-plug SATA/SAS (8) 2.5" hot-plug NVMe
Option 5 - (24) 2.5" hot-plug SATA/SAS/NVMe
Rear Basket:
Option 1 - (2) 2.5" hot-plug SATA/SAS
Option 2 - (2) 2.5" hot-plug NVMe

Fans: (6) Hot-swappable, redundant

Interface:
Internal ports: (2) USB 3.0, (1) USB 3.0 Type A, (1) OCP SAS module slot
External ports: D-Sub VGA based on Aspeed A ST 2600 (1) COM external RJ-45 Dedicated 1 Gbit/s RJ-45 control port
Expansion ports: (2) SATADOM; (2) Hot-swap SD card; (2) M.2 221 10 SATA/ PCI-E; (4) OcuLink NVMe; USB 3.0

Disk Bays: (2) SATADOM (2) Hot-swap SD card (4) Hot-swap 2.5" SATA/SAS/NVMe (4) Hot-swap 3.5" SATA/SAS/NVMe

NIC: I350-1G, 4 ports, PXE-Boot support

Storage Сontroller:
Intel RSTe 5.0 RAID 0/1/10/5;
support VROC RAID 0/1/10/5 NVMe

Management:
Dedicated 1G control port based on Aspeed AST2600 controller
*Monitoring of the main temperature sensors (additional as part of the UtiNet View 2.x pack)
*Automatic fan speed control
*Support for KVM and Virtual Media functions
*Support for IPMI 2.0 and Redfish standards
*Protection built into the BIOS of the NSD (ViPNet SafeBoot)
*Case opening sensor
*RAID controller management (monitoring, VD creation/editing, NVMe management, controller fine-tuning)
