Processor Family: Intel ® Xeon ® Scalable 1, 2, Ref generation
CPU number: 1 or 2
Cores: up to 28
L3 Cache: up to 35.5 MB
CPU Frequency: up to 4.4 GHz
Form Factor: 2U Rack
Рower:
Option 1 - 550W 1+1 redundancy / single
Option 2 - 800W 1+1 redundancy / single
Option 3 - 1200W 1+1 redundancy
Option 4 - 2200W 1+1 redundancy
Expansion Slots:
Option 1 - (3) PCI-E x16 LP / (3) PCI-E x8 LP; Option 2 - (2) PCI-E x16 W / (5) PCI-E x8 LP
Maximum Capacity:
up to 4096GB DIMM Memory Module, Adaptive Data Correction (SR), SDDDC. ADDDC
DIMM Slots Available: 16 DIMM slots
DDR4: up to 2933 MHz DDR4ECCRegister
Memory protection:
Advanced ECC Registered Optane DC Persistent Memory Module (SDDC), Adaptive Data Correction (SR), SDDDC, ADDDC
Drive:
Front basket:
Option 1 (3U) - (16) 3.5"/2.5" hot-plug SATA/SAS
Option 2 (3U) - (18) 3.5"/2.5" hot-plug SATA/SAS
Option 3 (4U) - (36) 3.5"/2.5" hot-plug SATA/SAS
Option 4 (4U) - (16) 3.5"/2.5" hot-plug SATA/SAS (4) 2.5" hot-plug NVMe
Rear basket (3U/4U):
Option 1 - (2) 2.5" hot-plug SATA/SAS
Option 2 - (2) 2.5" hot-plug NVMe
Fans: Option 1 - (3+1) Hot-swappable, with redundancy; Option 2 - (4+1) Hot-swappable, with redundancy
Interface:
Internal ports: (2) USB 3.0, (1) USB 3.0 Type A, (1) USB 2.0
External ports: D-Sub VGA based on Aspeed AST 2600 (1) COM external Dedicated control port 1 Gbit/s RJ-45
Expansion ports: (2) SATADOM; (2) Hot-swap SD card; (2) M.2 2280 SATA/PCI-E; (4) OcuLink NVMe; USB 3.0
Disk Bays: (2) SATADOM; (2) Hot-swap SD card
Storage Сontroller:
Intel RAID (RAID 0, 1, 5, 10) RSTe or VROC
Management:
Dedicated 1G control port based on Aspeed AST2600 controller
*Monitoring of the main temperature sensors (additional as part of UTINET Uview 2xPack)
*Automatic fan speed control
*Support for KVM and Virtual Media functions
*Support for IPMI 2.0 and Redfish standards
*Protection built into the BIOS of the NSD (ViPNet SafeBoot)
*Case opening sensor
*RAID controller management (monitoring, VD creation/editing, NVMe management, controller fine-tuning)1
